Simulation Laboratory
Digital Signal Processing (DSP) is concerned with the representation of signals as a sequence of numbers and the operations carried out on the signals to extract specific information contained in them. The DSP Lab is based on MATLAB Software which is used for identifying and describing discrete and digital signals & systems. This lab also helps us to analyze how digital signals are different from analog counterparts. By this lab one can evaluate the effectiveness of FFT algorithms in DFT implementation.




Laboratory Facilities
Sl. No. | Name of the Equipment’s | Specifications |
---|---|---|
1 | Desktop Computers | I5-4670S, 4GB RAM, Intel Core, 500GB Hard Disk |
2 | Software | Multisim |
PSPICE | ||
MATLAB | ||
3 | TMS320C5416 | Evaluation Board |
4 | TMS320C6713 | Evaluation Board |
