Digital Communication Laboratory
The digital communication Systems Laboratory intends to cover the basic understanding of functionalities of various block-sets involved in communication system. It involves system design and simulation exercises using MATLAB and Simulink and experiments based on Hardware trainer kits. This lab focuses the fundamental concepts on TDM, Pulse modulations, digital modulation techniques, source coding techniques and Error-control coding techniques.
Laboratory Facilities
| Sl. No. | Name of the Equipment’s | Specifications |
|---|---|---|
| 1 | Desktops | I5-4670S, 4GB RAM, Intel Core, 500GB Hard Disk |
| 2 | Software | Multisim Software |
| Matlab | ||
| 3 | Pulse Code Modulation and Demodulation kit | TDM Pulse code Modulation Transmitter |
| 4 | Pulse Code Demodulation Receiver | |
| 5 | Analyse Nyquist Criterion on Signal Sampling and reconstruction Trainer Kit | Signal Sampling & Reconstruction Trainer |
| 6 | Differential pulse code modulation Trainer kit ADCL-07 | DPCM transmitter & Receiver |
| 7 | Delta Modulation and Demodulation DM Trainer Kit ST-2105 | Delta, Adaptive Delta & Delta Sigma Transmitter & Receiver |
| 8 | Line coding trainer kit | Data Formatting & Carrier Modulation/Transmitter |
| 9 | Line decoding trainer kit | Data Reformatting & Carrier Modulation/Transmitter |
| 10 | Digital Storage Oscilloscopes | 200 MHZ, 2 Channel |
| 11 | Arbitrary Function Generators | 25MHZ, 2 Channel |
| 12 | Digital Multimeters |
