Antenna and Microwave Laboratory
The Antenna and Microwave Lab comprises of Klystron work bench that is used characterize microwave devices such as Circulators, Microwave Tees and Phase Shifters. The setup is also used for measurement of antenna patterns.
Laboratory Facilities
| Sl. No. | Name of the facility |
|---|---|
| 1 | Reflex Klystrons |
| 2 | Variable Attenuators |
| 3 | Crystal detectors |
| 4 | E plane Tee |
| 5 | H plane Tee |
| 6 | Magic Tee |
| 7 | Circulators |
| 8 | Isolators |
| 9 | Directional Couplers |
| 10 | Phase Shifters (ferrite) |
| 11 | Horn antenna |
| 12 | Parabolic dish antenna |
| 13 | Slotted Line Carriages |
| 14 | 50 ohm loads |
| 15 | Measurement of dielectric strength |
| 16 | Agilent Spectrum Analyzer (9 KHz 1.5 GHz) |
| 17 | CXA Signal Analyzer N9000A (9 KHz 7.5 GHz) |
| 18 | Microwave Signal Source, X band, 7.8?—?10.4 GHz |
| 19 | VSWR Meter (70db range) |
| 20 | Power Divider |
| 21 | Low Pass Filter |
| 22 | High Pass Filter |
| 23 | Band Pass Filter |
| 24 | Patch Antenna (Single Rectangle Patch) |
| 25 | EM Coupled Patch (2×1 patch) |
| 26 | Slot Antenna |
| 27 | Antenna Tripod Stand (Tx and Rx) Manual Type |
| 28 | Schottky Coaxial Detector |
| 29 | Coaxial matched Loads 50ohms |
| 30 | Short |
| 31 | Digital Storage Oscilloscopes |
| 32 | Digital Multimeters |
| 33 | Breadboards |
| 34 | Wire Cutters |
| 35 | Extension Boxes |
| 36 | Accessories |
