Physics Lab 2
67sq m
Total area of the lab
Salient Features
| S.No | Name of the Facility | Specifications | Quantity |
|---|---|---|---|
| 1 | Reflector | 45 degree reflector | 4 No. |
| 2 | Air Wedge | Glass plates:2“x1” | 4 No. |
| 3 | LENS | Focal length=100cm | 3 No. |
| 4 | Sodium Vapour Lamp | 35W with Lamp House & Transformer | 3 No. |
| 5 | Diffraction Grating | Standard-15000 LPI | 2 No. |
| 6 | Mercury vapour lamp | direct type | 2 No. |
| 7 | Lamp house | for Hg | 2 No. |
| 8 | Magnifying lens | small | 12 No. |
| 9 | Spirit level | for spectrometer initial adjustment | 3 No. |
| 10 | Photoelectric effect experimental kit | For optics experiments | 1 No. |
| 11 | Optical Breadboard with Rigid Support (800x600mm) | For optics experiments | 1 No. |
| 12 | Kinematic Laser Mount, Beam Splitter Mount | For optics experiments | 1 No. |
| 13 | Mirror Mount with Precision Translation Stage | For optics experiments | 1 No. |
| 14 | Rotation Stage, Screen with Mount | For optics experiments | 1 No. |
| 15 | Polarizer Rotator with Mount(Resolution 1°) | For optics experiments | 1 No. |
| 16 | Cell Mount | For optics experiments | 1 No. |
| 17 | XYZ Translation Stage(Resolution 0.01mm) | For optics experiments | 1 No. |
| 18 | Laser Fiber Coupler(Magnification 10X) | For optics experiments | 1 No. |
| 19 | Meter Scale Mount | For optics experiments | 1 No. |
| 20 | Fiber Chuck Holder | For optics experiments | 1 No. |
| 21 | PMMA Rod and its mount | For optics experiments | 1 No. |
| 22 | Fiber Bending Loss Apparatus | For optics experiments | 1 No. |
| 23 | Multi Mode Optical Fiber(735,240 microns) | For optics experiments | 1 No. |
| 24 | Mirror with Cell(?25 mm) | For optics experiments | 1 No. |
| 25 | Beam Splitter(50x50 mm) | For optics experiments | 1 No. |
| 26 | Plano Convex Lens with Cell(?30 mm) | For optics experiments | 1 No. |
| 27 | Diffraction Cells | For optics experiments | 1 No. |
| 28 | Colour Filters | For optics experiments | 1 No. |
| 29 | Glass Tank(100x100x50 mm) | For optics experiments | 1 No. |
| 30 | Mounted Opto-Electronic Detectors | For optics experiments | 1 No. |
| 31 | Opto-Electronic Measurement Unit(230V AC / 50Hz) | For optics experiments | 1 No. |
| 32 | Diode Laser with Power supply (Red) | For optics experiments | 1 No. |
| 33 | Diode Laser with Power supply (Michelson Red) | For optics experiments | 1 No. |
| 34 | Diode Laser with Power supply (Red, without Lens) | For optics experiments | 1 No. |
| 35 | Detector Output Measurement Unit | For optics experiments | 1 No. |
| 36 | Prism | Experiment set | 3 No. |
| 37 | Grating constant by normal incidence complete | Experiment set | 3 No. |
| 38 | Specific rotation of a solution using polarimeter kit | Experiment set | 3 No. |
| 39 | wavelength of a semiconductor laser diode by diffraction method kit | Experiment set | 3 No. |
