Physics Lab 1
65sq m
Total area of the lab
Salient Features
| S.No | Name of the Equipment’s | Specifications | Quantity |
|---|---|---|---|
| 1 | Thermal diffusivity measurement | brass | 1 No. |
| 2 | Stefans constant determination | 1 No. | |
| 3 | Thermal relaxation measurement | 10W Bulb | 1 No. |
| 4 | Thermal and electrical conductivity measurement | copper | 1 No. |
| 5 | low Heat Resistance measurement | used with lock in amplifier | 1 No. |
| 6 | Oscillator | Model: SEG 201 | 3 No. |
| 7 | Carey foster bridge | 1meter | 3 No. |
| 8 | Galvanometer | MR 100,0 30 divisions | 3 No. |
| 9 | Resistance box | 10000,1000,100 ohms and 2ohm and 0.5 - 2ohm | 18 No. |
| 10 | IC Regulated battery eliminator | Range: 2 - 12V DC/2A | 3 No. |
| 11 | Regulated Power supply | 30V & 3A | 1 No. |
| 12 | Temperature Controller | Up to 400c | 1 No. |
| 13 | Constant current source | low current 0 - 20mA & high Current 20mA- 500mA | 2 No. |
| 14 | Signal generator | 30Hz to 300KHz | 2 No. |
| 15 | DC Differential amplifiers | 4 inputs | 2 No. |
| 16 | AC Bridges | Maxwell, Anderson etc | 1 No. |
| 17 | Capacitor box | upto 250pF | 1 No. |
| 18 | Lock in Amplifier | upto 10kHz and 250microvolt | 1 No. |
| 19 | Power amplifiers | 30 - 30kHz & 10W | 1 No. |
| 20 | Insert for calibration of secondary thermometers | silicon diode and copper-constant thermocouple | 1 No. |
| 21 | Insert for temperature coefficient of resistance | copper and band gap of semiconductor | 1 No. |
| 22 | Capacitor measuring circuit | Capacitance meter | 1 No. |
| 23 | Cylindrical Capacitor jar | to measure dielectric constant of liquids | 1 No. |
| 24 | Mutual inductance coil | used with lock in amplifier | 1 No. |
| 25 | Variable Load | used with lock in amplifier | 1 No. |
| 26 | Calibration for differential amplifiers | used with lock in amplifier | 1 No. |
| 27 | Circuit for Filters | high, low and band pass | 1 No. |
| 28 | Insert for verification for Currie law | Ferro electric material | 1 No. |
| 30 | Tubular furnace | upto 400c | 1 No. |
| 31 | Gamma Ray Spectrometer | GR612 | 1 No. |
| 32 | Scintillation Detectors | SD151/152/152W | 1 No. |
| 33 | Sliding bench with scintillation detector stand & source stand | 1 No. | |
| 34 | Gamma Reference Standard Set | GS290 | 1 No. |
| 35 | Aluminium Absorber Disc Set | AA270 | 1 No. |
| 36 | Copper Absorber Set | CL275 | 1 No. |
| 37 | Geiger Counting System | GC601A/GC602A | 1 No. |
| 38 | End Window G.M.Tube (Halogen Quenched) | GM120+GM125 | 1 No. |
| 39 | G.M. Detector (End window) stand | SG200 | 1 No. |
| 40 | Radioactive Source Kit | SK210 | 1 No. |
| 41 | Beta Source | Sr90 | 1 No. |
| 42 | Lead Shielding | LS240 | 1 No. |
| 43 | Aluminium Absorber Set | AA270 | 1 No. |
| 44 | Absorber Set | AS272+AS273 | 1 No. |
| 45 | MINIM Gamma Ray Spectrometer | GR611M | 1 No. |
| 46 | scintillation detector | SD151/152/152W | 1 No. |
| 47 | Sliding bench with scintillation detector stand & source stand | 1 No. | |
| 48 | Gamma Reference Standard Set | GS290 | 1 No. |
| 49 | Lead Absorbers Set | LA271 | 1 No. |
| 50 | Software tutor for Experiments with Gamma Ray Spectrometer | 1 No. | |
| 51 | Data Communication Software for downloading the Counter / Timer unit stored readings into PC | Software | 1 No. |
| 52 | Cathode ray Oscilloscope | 70 MHz, 2 Channels (Convergent/ Tektronix) | 2 No. |
| 53 | Specific heat by Newton’s law of cooling Apparatus | Experiment set | 3 No. |
| 54 | Stefan’s constant by Emissivity method Apparatus | Experiment set | 3 No. |
| 55 | Calibration of thermistor by Temperature measurement Method | Experiment set | 3 No. |
| 56 | Calibration of thermocouple for temperature measurement apparatus | Experiment set | 3 No. |
| 57 | Thermal conductivity of bad conductor by Lee Charlton method Apparatus | Experiment set | 3 No. |
| 58 | Verification of Stefan’s Boltzmann law using potentiometer | Experiment set | 3 No. |
| 59 | Searle’s apparatus determination of thermal conductivity of Cu | Experiment set | 3 No. |
| 60 | A.C. frequency using a sonometer Apparatus | Experiment set | 3 No. |
| 61 | Frequency of tuning fork by volume resonator apparatus | Experiment set | 3 No. |
| 62 | Lamp and scale arrangement for ballistic galvanometer | Experiment set | 3 No. |
| 63 | Moment of Inertia irregular body with chuck nut | Experiment set | 3 No. |
| 64 | Young’s modulus by Uniform Bending | Experiment set | 3 No. |
| 65 | Fly wheel Experiment setup | Experiment set | 3 No. |
| 66 | Bar Pendulum Experiment (acceleration due to gravity) | Experiment set | 3 No. |
| 67 | Verification of parallel and perpendicular axis theorem | Experiment set | 3 No. |
| 68 | Stokes apparatus for viscosity | Experiment set | 3 No. |
| 69 | Spring’s constant experiment | Experiment set | 3 No. |
| 70 | Simple Pendulum(Dependence Of Period On Amplitude Mass) | Experiment set | 3 No. |
| 71 | Post office box 3 ratio plug type | Experiment set | 3 No. |
| 72 | Ballistic galvanometer | Experiment set | 3 No. |
| 73 | Tangent galvanometer | Experiment set | 3 No. |
| 74 | Study of Resonance in Seriesin LCR Circuits with Digital Meters | Experiment set | 3 No. |
| 75 | Oscillator for LCR circuits | Analog, 1 Hz to 100 KHz | 3 No. |
| 76 | Function Generator with digital frequency meter | 2 Hz to 2 MHz | 3 No. |
