Power Electronics and Drives Laboratory
The laboratory is well equipped with experimental set-ups for the analysis of power electronic drives, converters and drives.
Laboratory Facilities
| S.No | Name of the Equipment’s | Specifications |
|---|---|---|
| 1 | Study of Basic DC-DC Converter with MOSFET switch module/Control module | |
| 2 | Regulated Power | Supply +/- 15V,500mA |
| 3 | DC to DC Flyback Converter ower module/Control module | |
| 4 | Digital DC Voltmeter | 0-200V |
| 5 | Digital DC Ammeter | 0-2A |
| 6 | DC-DC Forward Converter | |
| 7 | 3Phase PWM Control Using FPGA Fed Induction Motor Control i/p | 230V,AC +/-10V,o/p 3 phase,220V AC +/- 10V |
| 8 | 3 Phase Induction Motor | ,0.5HP,220V,1440RPM |
| 9 | Static Characterstics of SCR PE 101 | 0-300V,1A |
| 10 | Unregulated Power Supply, | |
| 11 | Digital DC Voltmeter | 0-30V |
| 12 | Digital DC Ammeter 0-200micro A | |
| 13 | Rheostat | 0-25 Ohms,6A, 0-200 Ohms,2A |
| 14 | AC Voltage Controller Using TRIAC & DIAC PE263 | |
| 15 | Oscilloscope 30Mhz,Dual Channel | 30Mhz |
| 16 | Static Characterstics of Mosfet & IGBT PE 102 | |
| 17 | R & RC Triggering circuit PE266 | |
| 18 | Step down Transformer | 240V/115 |
| 19 | Lamp load mounted on a holder with terminals 100W bulbs | 100W |
| 20 | SCR Turn on circuit UJT relaxation oscillator PE261 | |
| 21 | Single phase full wave rectifier with R & RL loads PE122/222 | |
| 22 | DC Jones chopper with R & RL load acitor, diode & auto transformer PE151/251 | |
| 23 | AC Voltage Controller Using TRIAC & DIAC with R & RL load PE263 | |
| 24 | Speed control of separately exited DC motor with fractional HP DC motor using SCR PE125/225 | |
| 25 | Oscilloscope 30Mhz,Dual Channel | 30Mhz |
| 26 | Isolation Transformer | (0-250VA, 0-230V, 1Henry 2KVA) |
| 27 | Step down Transformer | (230V/15V, 1A) |
