Microprocessor & Microcontroller Laboratory
The laboratory is well equipped with 8086 µp and 8051 µc to study and demonstrate the circuit interfacing with various I/O devices.
Laboratory Facilities
| S.No | Name of the Equipment’s | Specifications |
|---|---|---|
| 1 | Desktop Computers | I5-4670S, 4GB RAM, Intel Core, 500GB Hard Disk |
| 2 | Software | Talk |
| Keil | ||
| EMU 8086 | ||
| 3 | Oscilloscope | 70MHz,1GS/s |
| 4 | 8086 Microprocessor Trainer Kit With LCD display | 5V/2.5A; +/-12v,100mA |
| 5 | 8051 Microcontroller Trainer Kit With LCD display | 5V/2.5A; +/-12v,100mA |
| 6 | Interfacing Cards | 1. Stepper motor Interface (Interface Card and One motor) 2.LCD & Keyboard 3.Multiplexed Display & Keypad. |
| 7 | Study Cards | 8255 Study Card 8251/8253 Study Card 8279 Study Card |
| 8 | Embedded Boards | Arduino Boards, LPC 2148 |
