High Voltage and Relay Laboratory
The laboratory is well equipped with facilities for insulation testing, impulse generator, relays and circuit breaker for feeder protection.
Laboratory Facilities
| S.No | Name of the Equipment’s |
|---|---|
| 1 | AC 100KV and DC 140KV Transformer With control panel with accessories |
| 2 | Rod Gap Assembly Plane to Plane and Point to Point Electrodes |
| 3 | Oil Test Kit 60KV |
| 4 | 100mm Sphere Gap Assembly |
| 5 | 30KV High Voltage Tester with jig For solid insulating material - NOMAX |
| 6 | 100KV , 100mA High Voltage Test Bench With High voltage transformer and suitable reactor for insulator wet & dry Testing |
| 7 | Electrolytic Tank for Field Mapping |
| 8 | Nozzled Artificial Rain Making Apparatus With X & y Guage suitable water pump |
| 9 | Insulator string with guard Ring Insulator String Without Guard Ring |
| 10 | Impulse 150KV 225Joules 5 Stage 1.2p sec Wave Front & 50p sec Wave, tail impulse Generator |
| 11 | Earth Resistance Tester with earth rod kit |
| 12 | Electro Mechanical IDMT Directional Relay 2TJM12 |
| 13 | Electro Mechanical type Over Current Relay Non directional Relay-2TJM10 |
| 14 | Directional and Non-Directional Relay Trainer |
| 15 | Microprocessor Base Numeric Over Current Relay Non-Directional Relay MIT103 |
| 16 | Electro Mechanical Over Voltage Relay MVDG11 |
| 17 | Microprocessor based static O/U Volts Relay MV-12 |
| 18 | Negative Sequence Relay CTNM12 |
| 19 | Differential Relay Single Phase Differential Relay MBCH12 |
| 20 | Feeder Protection scheme |
| 21 | Air Circuit Breaker |
