| 1 |
DC Shunt Motor |
(3KW,220V,1500RPM) |
| 2 |
DC Shunt Generator test Rig With Control Panel |
(2.2KW,220V,1500RPM) |
| 3 |
Variable Lamp load |
(240V/3.6 KW) |
| 4 |
DC Series Motor Test Rig with Mechanical Load |
(3KW, 220V, 1500RPM) |
| 5 |
DC Compound Motor |
(3KW,200V,1500RPM) |
| 6 |
DC Compound Generator Test Rig |
(2.2KW, 220V,1500RPM) |
| 7 |
Two identical DC Shunt Machines Test Rig |
(3KW, 220V,1500RPM) |
| 8 |
DC Panel Mount Centre Zero Voltmeter |
(600-0-600V) |
| 9 |
Single Phase Transformer Experimental set up |
(2 No's of Single Phase Transformer 230/230V,2KVA) |
| 10 |
Single Phase Variac |
(250V, 15A) |
| 11 |
Three Phase Transformer Experimental set up |
(3 No's of Single Phase Transformer 415,230V,2KVA) |
| 12 |
Variable Resistive load |
(240V/3.6 KW) |
| 13 |
Rheostat |
(300E/2A), (600E/2A) |
| 14 |
Cut section of dc motor |
|
| 15 |
Copper wire |
(2.5sq, mm) |
| 16 |
Crimping tool |
|
| 17 |
Ac Analog |
Voltmeter (0-500V) |
| 18 |
Digital Multimeter |
|
| 19 |
Three Phase Variac |
(470V, 20A) |
| 20 |
Phase Sequence Indicator |
|
| 21 |
3 Phase Synchronous Motor |
(5KVA, 415V, 1500RPM) with Mechanical Load test Rig |
| 22 |
Single Phase Induction Motor |
(2HP, 230V, 50Hz, 1500RPM) Test Rig |
| 23 |
3Phase Squirrel Cage Induction Motor |
(5HP, 440V, 50Hz, 1440RPM) with Mechanical Load |
| 24 |
Three Phase Variac |
(0-415V, 15A) |
| 25 |
3Phase 4 Pole Slip Ring Induction Motor |
(3HP, 415V, 50Hz, 1440RPM) Test Rig with Mechanical Load |
| 26 |
Three Phase Variac |
(0-460V, 15A) |
| 27 |
3Phase 4 Pole Slip Ring Induction Motor |
(3HP, 415V, 50Hz, 1440RPM) Test Rig with Mechanical Load |
| 28 |
Three Phase Variac |
(0-460V, 15A) |
| 29 |
DC Shunt Motor |
(5.2KW, 220V, 1350RPM)-3Phase Alternator Set(3.5KVA, 415V, 50Hz, 1500RPM) Synchronizing Panel |
| 30 |
3 Phase Induction Motor |
(3HP, 440V, 50Hz, 1500RPM) DC Shunt Generator Test Rig(3.5KW, 220V, 1500RPM) |
| 31 |
Single Phase Transformer Experimental set up |
(2 No's of Single Phase Transformer 230/230V,2KVA,1KVA) |
| 32 |
Single Phase Variac |
(250V, 10A) |
| 33 |
Cut section view of Induction Machine |
(0.5HP/415V) |
| 34 |
Variable 3phase Output 4A lines |
(5A-10A) |
