Digital logic design Laboratory
The laboratory is well equipped with experimental set-ups to analyze logic gates, sequential and combinational logic circuits.
Laboratory Facilities
| S.No | Name of the Equipment’s | Specifications |
|---|---|---|
| 1 | Desktop Computers | I5-4670S, 4GB RAM, Intel Core, 500GB Hard Disk |
| 2 | Software | Logic Sim |
| MATLAB | ||
| 3 | Oscilloscope | 70MHz,1GS/s |
| 4 | Digital IC Trainer Kits | 16 Pin Sockets |
| 5 | Logic Gates | Basic Gates: 7400,7402,7404,7408,7432,7486,7410,7420,4075,7411 4 Bit Binary Adder: 7483 Decoder: 7447 4 bit Synchronous Counter: 74193 4:1 Multiplexer: 74153 1:4 Demultiplexer: 74139 Decoder: 74138 J K Flip Flop: 7476 Decade Counters: 7490 Comparator: 7485 Shift Registers: 7495 |
| 6 | Universal IC Tester | IC Tester |
| 8 | Digital Multimeter |
