Circuit Measurement laboratory
The laboratory is well equipped with measuring instruments and experimental set ups for analysis of electrical circuits.
Laboratory Facilities
| S.No | Name of the Equipment’s | Specifications |
|---|---|---|
| 01 | Terminals Boards Fixed on A Base with terminals | - |
| 02 | Digital Multimeter | - |
| 03 | 40 W Tube Light Choke | 40 W |
| 04 | PCB Mounted Resistor | 150E,2W |
| 05 | PCB Mounted Resistor polyster capacitor | 0.01PF |
| 06 | Transformers | 230V/230V,250VA |
| 07 | Single Phase Varic | 270VA/2A |
| 08 | AC Portable Voltmeter | 0-300V |
| 09 | AC Portable Ammeter | 0-2A |
| 10 | Portable Wattmeter 0- | 300V,0-2A UPF |
| 11 | Portable Dyanamometer Type Wattmeter | 0-600V,0-10A,UPF |
| 12 | Portable AC Ammeter | 0-10A |
| 13 | Kelvin Double Bridge with Accessories | - |
| 14 | Maxwells Bridge with Accessories | - |
| 15 | De-Sautys Bridge with Accessories | - |
| 16 | Dual Channel Digital Oscilloscope | - |
| 17 | Megger | - |
| 18 | Three Phase transformer | - |
| 19 | AC Digital Ammeter | - |
| 20 | Functional Generator | - |
